The Flatpack2 DC/DC 18–75V converters add secondary 24 VDC or 48 VDC outputs to a Flatpack2 power system, powered from the main battery. Each 1350 W module accepts a wide 20–75 VDC input and provides galvanic isolation between loads. Its isolated CAN bus connects to the Eltek system controller, so the converters are monitored and controlled without a separate controller.
Key Features
- Wide input range: 20–75 VDC
- 1350 W, 24 VDC (56 A) or 48 VDC (28 A) output
- Galvanic isolation between loads
- OR-ing protection on output
- Boost mode and quick-trip pulse
- Up to 91.7% efficiency
- Module keying, seamless integration in the Eltek control system
Technical Specifications
| Specification | 24V output | 48V output |
|---|---|---|
| Input | ||
| Voltage Range | 20 – 75 VDC (shutdown < 16.5 VDC) | |
| Current (maximum) | 70 ADC (85 ADC during boost) | |
| DC Output | ||
| Max Power | 1350 W | |
| Voltage (adjustable range) | 24 – 28 VDC | 48 – 58.5 VDC |
| Current (maximum) | 56 ADC | 28 ADC |
| Others | ||
| Efficiency | Up to 91.7% | |
| Operating Temperature | −40 to 75°C | |
| Storage Temperature | −40 to 85°C | |
| Dimensions | ||
| Dimensions (W x H x D) | 109 x 41.5 x 327 mm [4.29 x 1.63 x 12.78 inch] | |
| Weight | 1.95 kg | |
| Certifications | ||
| Safety | UL 60950-1, EN 60950-1 | |
Specifications from Delta Electronics (Eltek) and subject to change without notice. Contact KPS for the latest datasheet.
Applications
Isolated 24V or 48V secondary supplies from a main telecom or industrial battery, for radio, transmission and control equipment.
